Frameset
Frame
6061 aluminum alloy frame with added reinforcements at critical points
Fork
Heavy-duty steel fork
Wheels
Front Hub
Alloy front hub with sealed cartridge bearings
Rear Hub
Alloy flip/flop rear hub with 14mm axle and sealed cartridge bearings
Rims
29″ x 36h double- wall alloy rims
Spokes
14g stainless steel spokes
Tires
29″ x 2.30 Vee Tire Co. Speedster tires
Drivetrain
Gearing
Single Speed
Crankset
3-piece tubular chromoly cranks
Chainring
33T alloy chainring with 15T rear sprocket
BB
8-spline quad bearing sealed cartridge bottom bracket
Chain
KMC S1 1/2″ x 1/8″ chain
Pedals
Alloy platform pedals
Components
Saddle
BlackOps Mullet Saddle
Seatpost
Alloy Seat Post with integrated clamp
Handlebar
Steel BMX handlebar
Grips
Rubber mushroom style BMX grips
Stem
Alloy 4-Bolt 1-1/8″ threadless stem
Headset
Steel 1-1/8″ threadless headset
Brakes
Brakeset
Rear Tektro V-Brake
Accessories
Pads
Digital camo 3-piece pad set
Pegs
Rear Pegs
Chain Guard
Smoke clear plastic chain guard
Weights
Bike Weight
30.5 Lbs
Rider Weight Limit
250 Lbs
| KEY | mm | inch | |
|---|---|---|---|
| Seat Tube Length (BB Center to Top) | A | 430 | 16.9 |
| Top Tube Length (Effective) | B | 620 | 24.4 |
| Chainstay Length | C | 469 | 18.5 |
| BB Drop | D | 65 | 2.6 |
| BB Height (BB Center to Ground) | E | 305 | 12.0 |
| Head Tube Length | F | 125 | 4.9 |
| Head Tube Angle | G | 71.0° | 71.0° |
| Seat Tube Angle | H | 71.0° | 71.0° |
| Wheelbase | I | 1105 | 43.5 |
| Fork Offset | J | 40 | 1.6 |
| Standover Height* | K | 750 | 29.5 |
| Frame Stack | L | 610 | 24.0 |
| Frame Reach | M | 406 | 16.0 |
| Seat Tube to Ground | N | 715 | 28.1 |
| Overall Length | O | 1832 | 72.1 |
| Crank Length | 175 | 6.9 | |
| Handlebar Width | 762 | 30.0 | |
| Stem Length | 50 | 2.0 | |
| Seat Post Length | 350 | 13.8 |
