Frameset
Frame
6061 aluminum alloy frame with added reinforcements at critical points
Fork
Heavy-duty steel fork
Wheels
Front Hub
Alloy front hub with sealed cartridge bearings
Rear Hub
Alloy flip/flop rear hub with 14mm axle and sealed cartridge bearings
Rims
29″ x 36h double- wall alloy rims
Spokes
14g stainless steel spokes
Tires
29″ x 2.30 Vee Tire Co. Speedster tires
Drivetrain
Gearing
Single Speed
Crankset
3-piece tubular chromoly cranks
Chainring
33T alloy chainring with 15T rear sprocket
BB
8-spline quad bearing sealed cartridge bottom bracket
Chain
KMC S1 1/2″ x 1/8″ chain
Pedals
Alloy platform pedals
Components
Saddle
BlackOps Mullet Saddle
Seatpost
Alloy Seat Post with integrated clamp
Handlebar
Steel BMX handlebar
Grips
Rubber mushroom style BMX grips
Stem
Alloy 4-Bolt 1-1/8″ threadless stem
Headset
Steel 1-1/8″ threadless headset
Brakes
Brakeset
Rear Tektro V-Brake
Accessories
Pads
Digital camo 3-piece pad set
Pegs
Rear Pegs
Chain Guard
Smoke clear plastic chain guard
Geometry
| KEY | mm | inch | |
|---|---|---|---|
| Seat Tube Length (BB Center to Top) | A | 286 |
11.3 |
| Top Tube Length (Effective) | B | 525 |
20.7 |
| Chainstay Length | C | 368 |
14.5 |
| BB Drop | D | 20 | 0.8 |
| BB Height (BB Center to Ground) | E | 237 |
9.3 |
| Head Tube Length | F | 102 |
4.0 |
| Head Tube Angle | G | 74° | 74° |
| Seat Tube Angle | H | 71° | 71° |
| Wheelbase | I | 939 |
37 |
| Fork Offset | J | 35 |
1.4 |
| Standover Height* | K | 570 |
22.4 |
| Frame Stack | L | 0.0 | 0.0 |
| Frame Reach | M | 0.0 | 0.0 |
| Seat Tube to Ground | N | 523.5 |
20.6 |
| Overall Length | O | 1441 |
56.7 |
| Crank Length | 165 |
6.5 |
|
| Handlebar Width | 700 |
27.6 |
|
| Stem Length | 50 | 2.0 | |
| Seat Post Length | 250 |
9.8 |
